background image

Pegasus Fast Start Guide

7460572 Rev A

Page 8 of 12

JUMPER FUNCTIONS


COM2 RS‐232/422/485 SELECTION (JRS1)
Using jumper JRS1, the COM2 port can be configured to operate in RS‐232, RS‐422 or RS‐485 mode.


Mode

Pins 1‐2 Jumper Pins 3‐4 Jumper Pins 5‐6 Jumper

RS‐232  (Default)

ON

OFF

OFF

RS‐422

OFF

ON

OFF

RS‐485

OFF

OFF

ON



COM2 RS‐422/485 FEATURE CONFIGURATION (JTM1)
Using jumper JTM1, the COM2 port RS‐422/485 features can be configured.
The default configuration is with no jumpers installed.


Feature

Jumper Setting

RS‐422/485 TX+ Pull‐up

Pins 1 & 2

RS‐422/485 TX‐ Pull‐down

Pins 3 & 4

RS‐422/485 Terminal 120ohm

Pins 5 & 6

RS‐422 Terminal 120ohm

Pins 7 & 8

RS‐422 RX+ Pull‐up

Pins 9 & 10

RS‐422 RX Pull‐down

Pins 11 & 12



CMOS SETUP (JBAT1)
Using jumper JBAT1, the CMOS can be retained or cleared.
Immediately after clearing CMOS the default BIOS should be loaded.


Mode

Jumper Setting

Keep CMOS  (Default)

Pins 1 & 2

Clear CMOS

Pins 2 & 3



LCD FEATURE CONFIGURATION (J1)
Using jumper J1, the frame rate and scan direction of the LCD device can be configured.


Feature

Jumper Setting

Frame Rate Low  (Default)

Pins 1 & 3 on

Frame Rate High

Pins 1 & 3 off

Scan Direction Low  (Default)

Pins 2 & 4 on

Scan Direction High

Pins 2 & 4 off



LCD BACKLIGHT VOLTAGE SELECT (JINV1)
Using jumper JINV1, the input power voltage for the LCD backlight can be selected.


Voltage

Jumper Setting

+5V  (Default)

Pins 1 & 2

+12V

Pins 2 & 3
