FS-97C User’s Manual Introduction
Product Specification 7
1.2
General Specification
Form Factor Full-size PICMG Single Board Computer
PICMG version 1.0 (Rev. 2.0), PCI version 2.0 compliant
CPU Intel® Core 2 Duo/ Core Duo/ Core Solo/ Celeron M processor
Package type: Micro- FCPGA478
Front side bus: 533/667MHz
Memory 2 x 240-pin DDR2 400/533/667MHz SDRAM
Maximum DRAM address decode space is 3GB.
Up to 10.67GB/s of bandwidth with dual-channel interleaved mode
Dual-Channel technology supported
Unbufferred, none-ECC memory supported only
Chipset Intel® 945GM(E) and ICH7-M
BIOS Phoenix-Award v6.00PG 4Mb PnP flash BIOS
Green Function Power saving mode includes doze, standby and suspend modes.
ACPI version 1.0 and APM version 1.2 compliant
Watchdog Timer System reset programmable watchdog timer with 1 ~ 255 sec./min.
of timeout value
Real Time Clock Intel® ICH7-M built-in RTC with lithium battery
Enhanced IDE UltraATA100 IDE interface supports up to 2 ATAPI devices
One 40-pin IDE port onboard
One CompactFlash Type II socket on solder side
Serial ATA Intel® ICH7-M integrates 2 Serial ATA interfaces
(No RAID Function)
Up to 150MB/s of transfer rate
Multi-I/O Port
Chipset Intel® ICH7-M with Winbond® W83627THG controller
Serial Port One RS232 and one jumper selectable RS232/422/485
USB Port 4 x Hi-Speed USB 2.0 ports with 480Mbps of transfer rate
Parallel Port One internal bi-direction parallel port with SPP/ECP/EPP mode
Floppy Port One internal Floppy port
IrDA Port One IrDA compliant Infrared interface supports SIR
K/B & Mouse PS/2 keyboard and mouse port
GPIO One 12-pin Digital I/O connector with 8-bit programmable
Smart Fan One CPU fan connectors for fan speed controllable
VGA Display Interface
Chipset Intel® 945GM(E) GMCH (Graphic Memory Controller Hub)
Memory Up to 224MB shared with system memory
Display Type CRT, LCD monitor with analog display, DVI,HDTV
Connector External DB15 female connector on rear I/O panel
Onboard 40-Pin LVDS connector
