Copyright 2004 9 Cheap Charlie Owner’s Manual
Canadian Comfort Industries www.dansons.com Dansons Group Inc.
Window
Burn Pot
Burn Grate
Heat Tubes
Tube Scraper
Ash Pit
Hopper
Fan Motors
Auger
Exhaust
Air Intake
Auger Motor
Base
Hopper Lid
I
NSTALLATION
C
HECK
L
IST
Unless you are knowledgeable and experienced in stove installation, we recommend your
Cheap Charlie
heater
receive a Pre-delivery Check and be installed by an Authorized
Cheap Charlie
Dealer.
COMPLETE THIS CHECK LIST PRIOR TO LIGHTING YOUR FIRST FIRE:
_____ Carefully read this "Owner's manual”. SAVE THIS MANUAL.
_____ Obtain final inspection and approval by local building officials.
_____ Carefully clean all marks off the brass parts before the first fire is lit. Use a soft cloth and a "Windex"
type cleaner. Caution: Never use an abrasive cleaner on any part of your stove.
_____ Polish the hopper to remove the oil type coating used in manufacturing.
_____ Have your Authorized
Cheap Charlie
Dealer demonstrate all the operational, cleaning and
maintenance steps necessary for your stove.
_____ Sign and keep a copy of the Pre-delivery Check List supplied by your Authorized Pelpro Dealer,
“Dansons Certified Installer”, found inside our appliance or available online.
Register online at
www.dansons.com/support for Extended Warranty.
______ Register your purchase online at www.dansons.com/support.
_____ Fill the hopper with quality pellets to prime the unit; Using the CCI “Acu-Tron”, (figure 5), PUSH the
FEED RATE Touch Pad and this will start the auger and the combustion fan.
NOTE: Do not attempt to light a fire at this time. Leave the START / FEED RATE [ON] for 2 to 5 minutes until
pellets start dropping into the burn grate. Then touch the OFF pad to turn off system . The auger is now primed to
deliver fuel to the burn grate (figure 6). Then light the stove according to the directions outlined in "LIGHTING
YOUR STOVE",
CCIAU –“AcuTron Board” Cutaway View
Figure 5 Figure 6
