Copyright 2004 31 Cheap Charlie Owner’s Manual
Canadian Comfort Industries www.dansons.com Dansons Group Inc.
A
PPENDIX
“A”
INSERTING, REMOVING & ADJUSTING THE BURN GRATE
The burn grate top, (G), must fit and seal firmly on the upper lips, of the burn box, (A). An
improper seal will allow incoming combustion air to escape, not passing up through the burn
grate thus reducing the amount of combustion air in the area needed to efficiently burn pellets.
A
B
C
G
Burn box
combustion air is brought
into the backside and
through the burn grate
bottom, back, and front
- Check periodically
for fly ash build up
-
“SUPER” Grate
Stainless steel
construction, slotted
bottom and air holes on
front and back
Adjustment Tab,
- used to fine tune, and
level burn grate
Upper Grate Lip
B
C
G
A
