Mechanical drawing (without heatspreader) – Delta Electronics E48SR12007 User Manual
Page 13
E48SR12007_05222008
13
MECHANICAL DRAWING (WITHOUT HEATSPREADER)
Surface-mount module Through-hole module
Pin No. Name Function
1
2
3
4
5
6
7
8
+Vin
ON/OFF
-Vin
-Vout
-SENSE
TRIM
+SENSE
+Vout
Positive input voltage
Remote ON/OFF
Negative input voltage
Negative output voltage
Negative remote sense
Output voltage trim
Positive remote sense
Positive output voltage
