Normal Operation Mode

During normal operating mode, the Optoma BC100B Emitter interprets 3D signals from the 3D‐XL
converter box and controls the Optoma ZF2100 Series LCD Shutter Glasses through RF. No LEDs are
active.

Signal Status (Strength) Indicator Mode

The signal status (strength) indicator provides a visual signal status measurement. The number of lit
blue LEDs indicates the quality of the sync signal, with more blue LEDs equating to better Sync signal.
The LEDs will display a red moving pattern while the emitter is attempting to acquire a 3D signal and
until a signal is found.

Manual Performance Tuning Mode

The Optoma BC100B Emitter and Optoma ZF2100  LCD Shutter Glasses are preprogrammed to work
with a wide variety of TVs and 3D content.  The manual performance tuning mode enables the 3D
system performance to be fine tuned.  Warning, use of this feature can result in improper or undesirable
operation.

3D Emitter & Glasses Pairing Mode

In environments where more than one Optoma BC100B Emitter is present, Optoma ZF2100  Glasses
should be paired with the emitter to ensure proper operation.  This mode also involves the Optoma
ZF2100  Glasses and is described in greater detail in a subsequent section.

Set Polarity Mode

This mode allows manual setting of lens polarity. During normal operation left lens will open when
rising sync edge is detected. Polarity can be reversed so that right lens will open when rising sync edge
is detected.

Factory Defaults Mode

In the event that the Optoma BC100B Emitter is not working properly and other troubleshooting
methods have failed, use the Reset to Factory Defaults mode to attempt recovery of proper operation.
Warning: Any tuning done using Manual Performance Tuning will be erased.

Connecting the Optoma BC100B Emitter to Optoma 3D‐XL converter box or Optoma
3D Projector

Use the guide in Connections: Optoma 3D‐XL converter
box with 3D Emitter Port to properly connect the Optoma
BC100B Emitter. When the Optoma 3D‐XL converter box
receives 3D signal or Optoma 3D projector is playing 3D
signal, the Optoma BC100B Emitter will turn on as well.
The LEDs will display a red moving pattern while the
