TOYOTA 2011 Avalon - Manual (Page 459)

436
4-3. Do-it-yourself maintenance
AVALON_U (OM41428U)
Fuse Ampere Circuit
21 EFI No.1 25 A
Multiport fuel injection system/
sequential multiport fuel injection
system, fuel pump
22 HORN 10 A Horn
23 HEAD LH UPR 15 A Left-hand headlight (high beam)
24 HEAD RH UPR 15 A Right-hand headlight (high beam)
25 A/F 25 A Air fuel ratio sensor
26 WASHER 20 A Windshield washer
27 S-HORN 7.5 A Horn
28 DOME 7.5 A
Gauges and meters, clock, front
personal lights, door courtesy
lights, garage door opener, rear
personal lights, trunk light
29 ECU-B 10 A
Center display, multiplex
communication system
30 RAD No.1 15 A
Audio system, center display,
navigation system
31 EFI No.2 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
32 STOP No.2 7.5 A
Stop lights, high mounted
stoplight, vehicle stability control
system, anti-lock brake system
33 HEAD RH LWR 15 A Right-hand headlight (low beam)
34 HEAD LH LWR 15 A Left-hand headlight (low beam)
