4

Mai

n

tenan

ce and care

435

4-3. Do-it-yourself maintenance

AVALON_U (OM41428U)

Fuse

Ampere

Circuit

9

STOP No.3

7.5 A

Electronic controlled transmission
system, multiport fuel injection
system/sequential multiport fuel
injection system

10

INJ

15 A

Multiport fuel injection system/
sequential multiport fuel injection
system

11

AM2

7.5 A

Starter system

12

DOOR No.1

25 A

Multiplex communication system

13

ALT-S

7.5 A

Charging system

14

ETCS

10 A

Multiport fuel injection system/
sequential multiport fuel injection
system

15

IG2

25 A

Multiport fuel injection system/
sequential multiport fuel injection
system, electronic controlled
transmission system

16

TURN/HAZ

15 A

Turn signal lights

17

AMP

30 A

Audio system

18

EFI No.3

7.5 A

Smart key system, electronic con-
trolled transmission system

19

STR LOCK

15 A

Steering lock system

20

STOP No.1

15 A

Multiplex communication system
