450

4-3. Do-it-yourself maintenance

Fuse

Ampere

Circuit

14

TAIL

10 A

Parking lights, license plate lights,
tail lights, front and rear side
marker lights

15

PANEL

7.5 A

Seat heaters, navigation system,
emergency flashers,
electronically controlled
automatic transmission system,
glove box light, instrument panel
lights, power outlets

16

ECU IG No.1

10 A

Center display, shift lock control
system, moon roof, multiplex
communication system, tire pres-
sure monitoring (warning) system

17

ECU IG No.2

10 A

Anti-lock brake system, automatic
headlight leveling system, vehicle
stability control system, multiplex
communication system

18

HTR

7.5 A

Air conditioning system,
instrument panel lights, electric
cooling fan

19

A/C COMP

7.5 A

Air conditioning system

20

GAUGE No.1

10 A

Back-up lights, navigation
system, emergency flashers

21

WIP

30 A

Windshield wipers

22

RR S/SHADE

10 A

Rear sunshade
