Re p la c ing co mp o n en ts – Mini 2011 Cooper Convertible User Manual
Page 142
Re
p
la
c
ing co
mp
o
n
en
ts
140
Replacing a fog lamp bulb
H8 bulb, 35 watts
1.
Turn in the wheel.
2.
Remove cover 2.
To do so, turn the cover counterclockwise.
3.
Pull the cable connector.
4.
Unscrew the lower bulb counterclockwise.
5.
To insert the new bulb and replace the
cover, proceed in reverse order.
Side turn signals
5 watt bulb, W 5 W
1.
Push the lamp with the ventilation grate for-
ward and remove.
2.
Unscrew the bulb holder counterclockwise.
3.
Pull out and replace the bulb.
4.
To insert the new bulb and replace the
cover, proceed in reverse order.
Tail lamps
1 Turn signal
LED
2 Tail lamp
bulb 21 Watt/5 Watt, W 5 W
3 Brake lamp
bulb 21 Watt/5 Watt, W 5 W
Lamp access
MINI:
Remove the cover from the sidewall of the cargo
area.
MINI Convertible:
Move the convertible top to its uppermost posi-
tion, refer to Loading aid page
, and remove
the cover of the luggage compartment side wall.
