ENGLISH
12
<1/3>
2>
<8/-, +/9>
SDB/TONE
SOURCE
DIRECT>
[RANDOM]
SOURCE
[CD 1/3]
[NUMBER]
[PROG/DIRECT]
[CLEAR/DEL]
[2]
[REPEAT]
[6, 7]
[8, 9]
[TIME/DISPLAY]
[DIMMER]
[VOLUME df ]
SDB/TONE [MUTE]
[o p]
Button located on both the main unit and the remote control
BUTTON
Button only on the main unit Button only on the remote control [BUTTON]Symbols used to indicate buttons in this manual Adjusting the tone1Use SDB/TONE to select the tone parameter to be adjusted.SDBBASSBALANCES. DIRECTTREBLE2Adjust the volume with <8/–, +/9>, [8, 9] or [o p].• To make other tone adjustments at this time, press SDB/TONE.• If no operation is performed for 5 seconds, the adjustment is retained and the normal display reappears. SDB Emphasizes the bass sound when the Super Dynamic Bass (SDB) function is set to ON. [Selectable modes] ON – OFF BASS Adjusts the bass sound. [Variable range] –10dB – +10dB TREBLE Adjusts the treble sound. [Variable range] –10dB – +10dBBALANCE Adjusts the left/right volume balance. [Variable range] L06 – CENTER – R06S.DIRECT Plays back a disc using the SOURCE DIRECT mode. During the SOURCE DIRECT mode, the audio signals
bypass the tone control circuits (SDB/BASS/TREBLE/
BALANCE), the music reproduction is more faithful to
the original sound.Settings made upon purchase:
• SDB .......................................OFF
• BASS ..................................... 0dB
• TREBLE ................................. 0dB
• BALANCE .......................CENTER
• S.DIRECT ..............................OFF• When “SDB” is ON, you can adjust “BASS”.
• This can also be set using .Operations possible during playback Muting the soundPress [MUTE].“MUTE ON” is displayed.To cancel, press [MUTE] again.(The mute mode is also canceled when the control is turned or a [VOLUME df] is pressed.) Switching the display’s brightnessPress [DIMMER].100 %70 %40 %Off• The display’s brightness switches each time the button is pressed. Listening with headphonesPlug the headphones (sold separately) into the .• The sound from the speakers is automatically cut off.NOTETo prevent hearing loss, do not raise the volume level excessively
when using headphones.
Button only on the remote control [BUTTON]
Symbols used to indicate buttons in this manual
Adjusting the tone
1 Use SDB/TONE to select the tone parameter to be
adjusted.
SDB BASS
BALANCE S. DIRECT
TREBLE
2 Adjust the volume with <8/– , +/9> , [8 ,
9] or [o p] .
• To make other tone adjustments at this time, press SDB/
TONE .
• If no operation is performed for 5 seconds, the adjustment is
retained and the normal display reappears.
SDB Emphasizes the bass sound when the Super Dynamic
Bass (SDB) function is set to ON.
[Selectable modes] ON – OFF
BASS Adjusts the bass sound.
[Variable range] –10dB – +10dB
TREBLE Adjusts the treble sound.
[Variable range] –10dB – +10dB
BALANCE Adjusts the left/right volume balance.
[Variable range] L06 – CENTER – R06
S.DIRECT Plays back a disc using the SOURCE DIRECT mode.
During the SOURCE DIRECT mode, the audio signals
bypass the tone control circuits (SDB/BASS/TREBLE/
BALANCE), the music reproduction is more faithful to
the original sound.
Settings made upon purchase:
• SDB .......................................OFF
• BASS ..................................... 0dB
• TREBLE ................................. 0dB
• BALANCE .......................CENTER
• S.DIRECT ..............................OFF
• When “SDB” is ON, you can adjust “BASS”.
• This can also be set using
.
Operations possible during playback
Muting the sound
Press [MUTE] .
“MUTE ON” is displayed.
To cancel, press [MUTE] again.
(The mute mode is also canceled when the control is
turned or a [VOLUME df ] is pressed.)
Switching the display’s brightness
Press [DIMMER] .
100 % 70 %
40 % Off
• The display’s brightness switches each time the button is pressed.
Listening with headphones
Plug the headphones (sold separately) into the
.
• The sound from the speakers is automatically cut off.
NOTE
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
