Page 13
11
NaimUniti 2 Setup
4.3.2 FM Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Seek Lock:
Low / Medium /
High. Sets the FM signal strength required
for the NaimUniti 2 tuner to identify an FM
station.
4.3.3 DAB Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Re-scan Stations:
Re-scans for DAB
stations.
Note:
The NaimUniti 2 DAB input is not implemented in units
distributed in territories where Digital Audio Broadcasting is
unavailable.
4.3.4 iRadio Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Auto Disconnect:
Select time.
Auto-disconnect is provided so that
internet data usage limits are not
inadvertently exceeded by a NaimUniti 2
left connected to internet radio.
Browse History:
Yes / No. If
Yes
is specified NaimUniti 2
will display the last used station if it is
available when list mode is selected. If
No
is specified NaimUniti 2 will display the top
station selection menu.
4.3.5 UPnP™ (Network) Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Server History:
Yes / No. If
Yes
is specified NaimUniti 2 will remember the
last used folder if the UPnP™ server is still
available. If
No
is specified NaimUniti 2 will
display the full list of available servers.
4.3.6 USB/iPod Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Folder History:
Yes / No. If
Yes
is specified NaimUniti 2 will automatically
display the last used folder on the USB
device. If
No
is specified the top level
folder of the device will be displayed.
iPod Charging:
Always / Never. iPod battery charging
takes place
always
when the iPod is
connected or
never
takes place.
Note:
The non-charging option is provided because
there is a small reduction in iPod sound quality when
simultaneously charging and playing. This means however
that an iPod can potentially run out of power while playing
via the NaimUniti 2.
4.3.7 Front Panel Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
Format:
Auto / Analogue
/ Digital. If
Auto
is specified the front
panel input will automatically detect the
audio signal format (analogue or digital)
and configure the input appropriately.
Specifying
Analogue
or
Digital
will fix the
front panel input format.
4.3.8 Other Inputs
Parameter Options
Enabled:
Yes / No
Name:
User definable
Input Trim:
±10dB
AV Fixed Volume:
Yes / No
If
No
is selected the input will behave
normally. If
Yes
is selected the input
will operate at a fixed volume and
the NaimUniti 2 volume control will be
disabled. This enables NaimUniti 2 to
be used in multi-channel AV systems
with volume control handled by the AV
processor.
Take care when selecting AV
Fixed Volume
.
Note:
AV fixed volume is only available on RCA phono
analogue inputs.
4.4 The Speakers Menu
The Speakers setup menu
enables a variety of speaker
parameters to be adjusted.
The options are tabulated
and described in the following
sections:
Parameter Options
Type:
Large+Sub / Large / Small+Sub
Max. Volume:
0 to 100 (adjust using handset
6
or
5
keys)
Balance:
-10 to + 10 (adjust using handset
6
or
5
keys)
The speaker
type
options specify signal routing and high-
pass filtering settings.
DAB 4/4
Enabled:
Yes
Name:
DAB
Input Trim:
0
4
Re-Scan Stations
iRadio 4/5
Enabled:
Yes
Name:
iRadio
Input Trim:
0
4
Auto Disconnect: Never
UPnP 3/4
Enabled:
Yes
Name:
UPnP
4
Input Trim:
0
Server History
Yes
USB/iPod 4/5
Enabled:
Yes
Name:
USB
Input Trim:
0
4
Folder History:
No
Front 4/4
Enabled:
Yes
Name:
Front
Input Trim:
0
4
Format: Auto
Analogue 1
1/4
4
Enabled: Yes
Name:
Analogue 1
Input Trim:
0
AV Fixed Volume
No
FM 4/4
Enabled:
Yes
Name:
FM
Input Trim:
0
4
Seek Lock:
Medium
Speakers 1/3
4
Type: Large+Sub
Max. Volume:
100
Balance:
0
