TROUBLESHOOTING
SYSTEM WILL NOT OPERATE CORRECTLY IN AUTOMATIC MODE
1. Make sure Remote Switch is ON when attempting to
control with Remote Operators Control and OFF
when trying to control with the front panel controls.
2. Select Manual Mode on the AE120 front panel.
Attempt to move linear actuator with the Manual
Push Buttons. If linear actuator does not move:
a. Make sure there is no physical obstruction
or restriction to guide roll movement.
b. Check linear actuator limit switches. Both
limit switches should be closed, unless
linear actuator is at its travel limit.
3. Move web back and forth through sensor sensing
zone and determine if the Error Indicator lights up
symmetrically left and right as the web moves. If is
does not, recalibrate the system for the specific
sensor involved.
SPECIFICATIONS
SENSOR
AE20
PRODUCT NUMBERS:
AE120 ............................................................................912674
PH16B ...........................................................................912085
PH21 ..............................................................................912626
UH21 ..............................................................................912621
UH01 ..............................................................................912153
Type Infrared
Sensor
PHB &
PH2
Ultrasonic
Sensor
UH2
Ultrasonic
Sensor
UH0
Sensor Gap 1.18 in.
[30.0 mm]
1.34 in.
[34.0 mm]
1.89 in.
[48 mm]
Effective
Detecting
Length
±0.20 in.
[5.0 mm] ±0.06 in.
[1.5 mm]
±.31 in.
[8 mm]
Light Source
Wave Length
950 nm
(Near
Infrared Ray)
Ultrasonic
220 kHz
Ultrasonic
220 kHz
Ambient
Temperature
32° to 120° F
[0° to 50° C]
32° to 120° F
[0° to 50° C]
32° to 120° F
[0° to 50° C]
Power Supply
Voltage
100 to 240VAC (continuous input),
50/60 Hz
Power
Consumption
100 VA
Input
Photohead: PH16B & PH46
Ultrasonic Sensor: UH21 & UH01
Centering Sensor (Proximity Sensor)
Fine Adjuster (Optional)
Remote Controller: RP10 (Optional)
Lock Out Switch: N.O., 15VDC, 250mA
(Customer Supplied)
Limit Switches: N.C. (Customer Sup-
plied)
Output
DC Motor: 24VDC, 1.2 A
Lamp Power Supply: 12VDC, 1.8 W
End of Travel: Dry Contact, Rated 0.1 A,
250VAC, 0.1 A, 24VDC
Ambient
Temperature
32° to 120° F [0° to 50° C]
