10

FORM NO. L-20341-E-0208

Single sheet in Sensor gap

Set the Web Thickness Selector

Switch to the RIGHT side 0.008

In. - 0.031 in. [0.20-0.80 mm]

Abnormal

Two sheets in Sensor gap

Normal

None

Abnormal

1. Is the Sensor installed and

aligned properly?

2. Has dust accumulated

inside the Sensor tube?

(Clean the Sensor tube with an

air gun or remove the Sensor

tube for cleaning.)

3. Is the Sensor signal

calibrated correctly?

(See Sensor Signal Calibration.)

TABLE 3 SHEET FEED MODE OPERATIONS

WEB SPLICE ONLY (MODES 1 AND 4)

This mode is used for web feed machinery where the only
desired measurements are normal run and web splice
(See Table 1 for Output Configurations for Modes 1
and 4).

During normal run with a single thickness of web passing
through the Sensor, the Normal Run Indicator LED will
glow and the Web Break Relay at Terminals 7, 8, and 9
and the Web Splice Relay at Terminals 10, 11, and 12
will remain in their normal state.

CONDITION

STATuS

CORRECTIvE ACTION

Receiver

Emitter

45°

Normal

None

No Web in Sensor gap

Abnormal

Abnormal

1. Is the Sensor installed and

aligned correctly?

2. Has dust accumulated

inside the Sensor tube?

(Clean the Sensor tube with

anair gun or remove the Sen-

sor tube for cleaning.)

Single sheet in Sensor gap

Normal

Abnormal

Set the Web Thickness Selec-

tor Switch LEFT 0.002-0.008 in.

[0.05-0.20 mm].

None

OPERATION

(continued...)

(continued...)
