GENERAL SPECIFICATIONS
Size
Brake
Torque
(Nm)
Clutch
Torque
(Nm)
Weight
(Kg)
Min. Disengagement
Air Pressure (Brake)
(Bar)
Max. Engagement
Air Pressure (Clutch)
(Bar)
110-14 10 18 11 1.6 3
130-19 & 130-24 18 27 18 1.8 3.3
7-28 32 44 28 1.9 3.4
7-38 46 64 28 1.9 3.4
8-38 72 68 70 2.3 3.8
8-42 108 105 70 2.3 3.8
GENERAL SAFETY PRECAUTIONS
CAUTION
Use lifting aids and proper lifting
techniques when installing, removing,
or placing this product in service.
WARNING
This product is capable of emitting
a spark if misused therefore is
not recommended for use in any
explosive environment.
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
CAUTION
Watch for sharp features when
interacting with this product. The parts
have complex shapes and machined
edges.
WARNING
Ensure proper guarding of the product is
used. Nexen recommends the machine builder
design guarding in compliance with OSHA 29
CFR 1910 “Occupational Safety and Health
Hazards”.
CAUTION
Use appropriate guarding for moving
components. Failure to guard could
result in serious bodily injury.
CAUTION
Surface temperature may exceed
safe handling limits during
operation. Do not touch.
