89
Technical Specifications
Video specification
Resolution: 640 x 480 pixel
Sensor: 1/3" color CMOS sensor
Gain control: Automatic
Exposure: Automatic
White Balance: Automatic
Shutter: Electronics 1/60 ~ 1/15000 sec
Minimum Illumination: [email protected], 3000K color
Focal Length: 6.0 mm
Aperture: F=1.8
Focus Extent: 20 cm - “
Lens mounting: Fixed board lens, CS-mount type
Image (Video Setting)
Image compression: JPEG
Frame rate: 30fps@QCIF, 20fps@CIF, 3fps@VGA
Compression Rate selection: 5 level (Very Low, Low, Medium, High, Very
High)
Frame rate setting: 1, 5, 7, 15, 20, auto (depends on the video
format)
Video resolution: 160x120, 320x240, 640x480
Brightness control: Range 1- 128
Contrast control: Range 1- 128
Hue control: Range 1- 128
System Hardware
LAN Connector: One RJ-45 port to connect to 10/100Mbps
Ethernet, auto-sensed
Wireless LAN: Built-in 802.11b wireless LAN module
(Wi-Fi compliant)
Generic I/O Port: Four I/O ports, two for input and two for output
Total 8-pin:
Pin 1 Input Port (I+) Pin 5 Output Port (I+)
Pin 2 Input Port (I-) Pin 6 Output Port (I-)
Pin 3 Input Port (II+) Pin 7 Output Port (II+)
Pin 4 Input Port (II-) Pin 8 Output Port (II-)
Note:
The output voltage is DC 5V and maximum current is 100mA.
