I/O Connector
I/O Connector Definition for the Internet Camera
An 8-pole connector is provided for auxiliary I/O connections to the Internet
Camera.
The I/O connector provides the physical interface for 2 digital outputs and 2
digital inputs that are used for connecting a diversity of external alarm devices
to the Internet Camera such as IR-Sensor and alarm relay.
The digital input is used for connecting external alarm devices and once triggered
images will be taken and e-mailed.
The supported transistor output can give a maximum of DC 5V to the externally
connected alarm devices and once triggered the current will activate the devices.
In 11
In 12
In 21
In 22
Out 1 -
Out 1 +
Out 2 -
Out 2 +
In 11 & In 12 is a pair for digital input. It works at voltage 5V.
In 21 & In 22 is a pair for digital input. It works at voltage 5V.
Out 1+ & Out 1- is a pair for digital output. The output voltage
is 5V and the maximum current is 100mA.
Out 2+ & Out 2 - is a pair for digital output. The output voltage
is 5V and the maximum current is 100mA.
