11 Specifications
Engine specifications
11
}}
263
Engine designation B5254T7
Output A
kW/rps 169/83
hp/rpm 227/5000
Torque
Nm/rps 320/25-80
ft. lbs./rpm 236/1500-4800
No. of cylinders 5
Displacement (liters/cubic inches) 2.52/153.8
Bore (mm/in.) 83/3.27
Stroke (mm/in.) 93.2/3.67
Compression ratio 9.0:1
Spark plugs
type Volvo kit no. 30650379
gap inches/mm 0.027in./0.7mm
tightening torque ft. lbs./Nm 22.5 ft. lbs./30 Nm
A The engine specifications for horsepower and torque listed in this table are based on the use of premium fuel.
Charge air cooler (Intercooler)
Turbocharged engines employ a turbo-com-
pressor to force air into the engine inlet mani-
fold and a charge air cooler to cool the
compressed inlet air. The resulting increase in
air flow raises pressure in the intake manifold and increases engine power over that devel-
oped by the normally-aspirated engine. The
charge air cooler (which resembles a radiator)
