Wiring
Connect with a Standard Receiver
STELLA Port Function Remote Control Channel Type
P Camera Pitch. A dial, slider or separate transmitter's ELEV/THR stick.
S Control Mode 3 way switch
Important: When using standard receiver, 90
° Pitch is not supported.
Connect with a FUTABA S.BUS Receiver
※ The provided "Y" lead may be required.
Receiver Channel Function Transmitter Channel Requirements
8 Gimbal Pitch Control A proportional dial, slider or separate
transmitters ELEV/THR stick.
9 Gimbal Roll Control. You can disable this by
setting the “Remote Control Angle Limit” to
ZERO in the configuration software.
A proportional dial, slider or separate
transmitters AIL/RUD stick.
10 Control Mode 3 way switch
11 90
° Pitch
2 or 3 way Switch
Standard
Receiver
OSD or
Video Transmitter
3~6S Battery
STELLA
S.BUS Receiver
OSD or
Video Transmitter
3~6S Battery
S.BUS
STELLA
