2E229-110(8) V2SQ S-TRIM ASY, '04 F150, w/CLR 1
2A036-131 S/C PULLEY 3.125" 6-RIB w/FLG 1
2A046-120 BELT, GATES K061203 1
4FN012-011(8) DUCT, S/C INTAKE, '04 F150 1
4FN110-033 MTG PLATE ASY, '04 F150 1
2A017-462 SPACER, IDLER SMOOTH 6-RIB 2
2A017-102-740 SPACER, .74"L x 1"OD ?
2A017-102-205 SPACER, 1"OD x 2.055" LONG 2
2A017-087-077 SPACER, .875"OD x .770" LONG 6
4FA016-171 DUST COVER (IDLER PULLEY) 1
4FH016-150 IDLER PULLEY, 6-RIB SMOOTH 3" FLANGD 1
4FN010-010 BRKT, PWR STR RES, '04 F150 1
4FN010-033 PLATE, MTG, PRIMARY 1
4HS017-021 SPACER, S/C BOSS S2000 2
7A312-075 5/16-18 x 3/4" HXCS GR5 ZINC 2
7A375-175 3/8-16 x 1-3/4" HXHD GR5 PLT 5
7A375-225 3/8-16 x 2-1/4" HXHD G8 1
7A375-275 3/8-16 x 2-3/4" HXCS G8 P 1
7C010-055 M10-1.5 x 50 HXHD GR10.9 1
7C080-120 M8-1.25 x 120 HXHD ZN PLT 2
7F006-093 6mm NYLOCK NUT 2
7F375-017 3/8-16 NYLOCK NUT 1
7J250-001 1/4" SAE WASHER, PLTD 5
7J312-000 5/16" FLAT WASHER-SAE 4
7J375-044 3/8" SAE WASHER, PLTD 12
4FN110-040 MNT BRKT SPT, '04 F150 1
7A250-074 1/4-20 x .75" HHCS 2
2A017-750-03 SPACER, .13" 2
4FN130-026 OIL FEED LINE ASY, '04 F150 1
7P125-004 1/8"NPT x 90° x -4 JIC FTG 1
7P250-122 1/4" PIPE THRD AN917 TEE 1
7P250-123 1/4"NPT x 1-1/2" NIPPLE 1
7P250-250 1/4"NPT STR x -4 JIC FTG 1
7U100-055 TIE-WRAP, 7.5" NYLON 5
7U250-000-465 OIL FEED HOSE, 46.5" -4 STRT 1
4FN130-036 OIL DRAIN LINE ASY, '04 F150 1
7P375-055 3/8"NPT x 1/2" HOSE BARB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
7U030-036 1/2" OIL DRAIN HOSE 0.67'
4FN112-040 AIR INTAKE ASY, '04 F150 1
4FA012-012 INTAKE ELBOW, 90° w/o BOSSES 1
4FN012-040 COVER, AIR FILTER, '04 F150 1
7A250-075 1/4-20 x .75" HHCS 3
7F250-021 1/4-20 x NYLOCK NUT 3
7J250-001 1/4" WASHER SAE 4
7J250-150 1/4" FENDER WASHER 2
7P250-033 1/4" x 5/32" RED.UNION 1
7P250-125 1/4" BARBED MALE TEE 1
7P375-008 ELBOW, 3/8" x 90° UNION 1
7P375-050 3/8" HOSEMENDER 1
7R002-016 #16 GOLDSEAL HOSE CLAMP 2
7R002-056 #56 GOLDSEAL HOSE CLAMP 4
7R005-001 208-91 T-BOLT CLAMP 1
7S350-200 3-1/2" x 2" SLEEVE 1
7S350-300 3-1/2" x 3" SLEEVE 1
7U030-030 1/4" VACUUM HOSE 0.167'
7U030-046 5/32" VACUUM LINE 2.5'
7U030-056 3/8" PCV HOSE 3.25'
2004-2007 Ford 5.4L F-150
Part No. 4FN218-020(8)SQ
IMPORTANT : Before beginning installation, verify that all parts are included in the kit. Report any shortages
or damaged parts immediately.
7U100-061 GROMMET, 3/8"ID x 5/8" FLANGE 1
7U100-100 GROMMET, 1"ID x 1.38"OD, .12-GRV 1
7U133-100 HOSE, ELBOW, 90° x 1"ID, MOLDED 1
5W001-012 18-22GA BUTT CONNECTOR 13
5W018-010 18GA STD RED WIRE 1'
5W018-020 18GA WIRE, BLK 1'
5W018-090 18GA WIRE, BROWN 1'
5W018-080 18GA WIRE, BLUE 1'
5W018-240 18GA WIRE, WHITE/YELLOW 1'
5W018-030 18GA WIRE, GREY 1'
8A002-021 MAF, 3.8", '04 F150 1
8D001-001 STD COMP BYPASS VALVE 1
8H040-095 AIR FILTER, MOSSELMAN 4" FLG 1
4FN139-096 ASY, PCV INSTALL, '04 F150 1
7P375-106 PCV VALVE, FORD, 3/8" HOSE 1
7P625-375 REDUCER, 5/8" BARB TO 3/8" BARB 1
7R001-006 #6 STNLS HOSE CLAMP 2
7R001-008 #8 STNLS HOSE CLAMP 4
7U030-056 3/8" PCV/VAC RUBBER HOSE 1.6'
7U033-000 5/8" PCV HOSE .5'
8N301-260(8) POWER COOLER ASY, '04 F150 1
8N201-260(8) DISCHARGE ASY, '04 F150 1
8N101-260(8) CAC ASY, '04 F150, AIR/WATER 1
008341 POWERCOOLER DECAL 1
7P100-100 1"NPT x 1" BARB FITTING 1
7S350-303 ELBOW, 3.5" x 3.0" 90° w/LEG, SILICONE 1
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 2
7R002-048 #48 SAE TYPE “F” SS HOSE CLAMP 1
7R002-056 #56 GOLDSEAL HOSE CLAMP 1
8N055-050 PLASTIC CAP, SURGE TANK 1
7S275-200 2-3/4" x 2" SLEEVE 1
8N105-260 WATER TANK MTG ASY, '04 F150 1
4FN010-060 BRKT, WATER RES, 2004 F150 1
7A250-051 1/4-20 x .50" HXHD ZN PLT 3
7E010-075 #12 x 3/4" SHT METL SCRW, HEX 3
7J250-001 1/4"SAE WASHER, PLTD 3
7P500-026 1/2"NPT x 3/4" BARB 90° 1
7P500-034 1/2"NPT x 3/4" BARB 90° NICKEL PLATE 2
7P500-078 1/2"NPT x 3/4" HOSE FIT 3
7R007-001 NYLON CLAMP 1-1/8" 8
7U030-065 3/4" x 90° HOSE SHORT 1
7U038-000 3/4" HEATER HOSE 6'
8N055-030 TANK, LT1 AFTERCOOLER 1
8N006-010 WATER COOLER 1
8N107-260 WATER PUMP ASY, '04 F150 1
5W001-005 3/8" PLASTIC WIRE LOOM 3.5'
5W001-009 16-14GA MALE SLIDE INSULATED 1
5W001-046 16-14GA EYELET .33" HOLE 1
5W001-013 14-16AWG, SOLDERLESS CONNECTOR 2
5W001-022 T-TAP CONN, 14-16AWG 1
5W014-010 14GA STRD WIRE, RED, UL1015 3'
5W014-030 14GA STRD WIRE, BLACK 3'
7U100-044 TIE-WRAP, 4" NYLON 8
8F001-402 PUMP, WATER, PIERBURG 1
8N100-001 NYLON MOUNTING KIT 1
8F060-048 FUEL INJ, 48LB PENCIL, FACT. '03 COBRA 8
5A003-033 ECU TUNER, F150, 3V 1
