Vortech 1994-2000 Ford 3.8 Mustang - Manual (Page 7)

P/N: 4FF020-010
©2003 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
09JUN03 V2.1 (94-00 3.8L Mus.(4FF V2.1))
1999-2000 3.8L V-6 Mustang
Part No. 4FF218-020SQ/028SQ
PARTS LIST
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any
shortages or damaged parts immediately.
®
ENGINEERING, LLC
Part Number Description Quantity
4FF218-020SQ 99-01 MUST 3.8 V6 KIT 1
4FF111-021 MOUNTING BRACKET ASSY 3.8 V6 1
4FF011-021 Mounting bracket 1
4FF010-034 Mounting plate 1
7C010-066 10mm x 1.5 x 65 bolt 3
7C080-065 8mm x 1.25 x 65 1
7J375-044 3/8" Washer 3
7K312-001 5/16" Washer 1
7A375-100 3/8" - 16 x 1" Screw 5
7A375-075 3/8" - 16 x 3/4" Screw 5
7K375-040 3/8" Flat washer 10
7G010-175 12mm x 1.75 nut 1
2A046-114 Belt 1
4FA016-170 Idler pulley 1
4FD017-011 Idler spacer 1
7C012-050 12mm x 1.75 x 50mm Hex 1
4FA016-171 Dust shield 1
7J012-092 12mm Flat washer 2
2E228-350 V2SQ SUPERCHARGER ASSY 3.8 V6 1
4FF130-026 OIL FEED ASSY 1
7U030-026 1/4” Oil feed hose (3.16 ft.) 1
7P250-066 #4 swivel x 1/4” hose barb fitting 4
7P525-067 .525 Crimp ferrules 4
7U100-055 Tie wrap, 6" nylon 2
7P250-144 1/4" NPT x #8 fitting 1
7P250-082 1/4" NPT x #4 90
°
fitting 1
7P125-103 #4 x 45
°
Male elbow 1/8" NPT 1
7P250-034 1/4 NPT Strt., Tee 1
7U030-026 1/4" Oil feed hose (1.58 ft.) 1
4FF130-036 OIL DRAIN ASSY 3.8 V6 1
7U030-036 1/2” x 19” Oil drain hose (1.667 ft.) 1
7P375-017 3/8” NPT x 1/2” Bead straight barb 1
7R001-008 #8 Stainless hose clamps 2
7P375-045 45
°
Street elbow, 3/8" NPT 1
4FF112-010 AIR INTAKE ASSY 3.8 V6 1
4FG112-022 Inlet duct w/ ring 1
7U035-001 3-1/2" Flex hose (1.33 ft.) 1
7R002-056 #56 Hose clamps 2
7R002-052 #52 Hose clamps 2
8H040-030 Air filter 1
7J250-001 1/4" SAE washers 8
7F250-021 1/4"-20 Nylock nuts 4
7A250-075 1/4"-20 x 3/4" Socket head cap screw 4
7S325-100 3.25 x 1 Sleeve 1
7S350-200 3-1/2 x 2 Sleeve 1
4FA012-012 90
°
Intake elbow 1
Part Number Description Quantity
7U030-056 3/8" PCV hose (1.250 ft.) 1
7P250-045 1/4 NPT x 3/8 ID fitting 1
7R005-001 208-91 T-bolt clamp 3.75" 1
4FG110-050 MAF bracket assy. 1
7P375-016 3/8 Pipe plug 1
7U100-052 7/16 Rubber grommet 1
4FF101-003 A/C LINE SUPPLEMENT 1
5W018-020 18 Gauge std. black wire (1.333 ft.) 1
5W018-050 18 Gauge std. yellow wire (1.333 ft.) 1
5W018-070 18 Gauge std. green wire (1.667 ft.) 1
5W018-080 18 Gauge std. blue wire (1.667 ft.) 1
5W001-012 Solderless connector, 22 red gauge 8
5W001-007 3/16" Heat-shrunk tube (1.00 ft.) 1
7P375-039 5/8 x 90 ° Barb 1
7P625-016 5/8 Union 1
7U034-100 5/8 A/C hose (.312 ft.) 1
7R002-010 #10 Clamp 3
4FF112-130 DISCHARGE ASSY 99-01 V6 MUSTANG 1
4FF112-030 Duct, disch 99-01 V6 mustang 1
7P156-082 5/32 TEE 1
7R002-016 #16 Goldseal hose clamp 4
7R002-044 #44 Goldseal hose clamp 4
7S275-200 2-3/4 x 2 sleeve 2
7U030-046 5/32" vacuum line 1.333'
7U034-016 1" GS hose .708'
7U100-055 Tie wrap, 6" nylon 4
7U133-090 Rubber elbow, ø1.0" x 90 ° 1
8D001-001 Std comp bypass valve 1
7P375-106 PCV valve 1
4FL120-025 ECM CHIP PACKAGE 99-01 V6 1
5A101-016 MAF VOLTAGE CLAMP ASSY 1
4FF101-003 A/C LINE SUPPLEMENT 1
4FF014-030 FLEXIBLE EGR TUBE 1
5W001-051 JUMPER HARNESS 6
7P500-626 1/2" F NPT-5/8" TUBE CONN S.S. 2
8F060-038 FUEL INJECTOR, 38 LBS RAIL 6
2A046-113 BELT, K061130-GATES 1
vii
