Vortech 1994-2000 Ford 3.8 Mustang - Manual (Page 6)

P/N: 4FF020-010
©2003 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
09JUN03 V2.1
(94-00 3.8L Mus.(4FF V2.1))
vi
Part Number Description Quantity
4FF238-068 FMU (with lines) 1
6Z110-112 10:1 Fuel management unit 1
4FF145-010 Male fuel assy., 3.8 (from rail) 1
4FF145-012 Female line assy., 3.8 (to tank) 1
7U030-046 5/32" Vacuum line (6 ft.) 1
7P156-082 5/32" TEE 2
7U100-055 Tie wrap, 6" nylon 4
4FF130-036 OIL DRAIN ASSEMBLY 1
7U030-036 1/2” x 19” Oil drain hose (1.667 ft.) 1
7P375-017 3/8” NPT x 1/2” Bead straight barb 1
7R001-008 #8 Stainless hose clamps 2
7P375-045 45 ° Street elbow, 3/8" NPT 1
4FF112-010 AIR INTAKE ASSEMBLY 1
4FG112-022 Inlet duct w/ ring 1
7U035-001 3-1/2" Flex hose (1.33 ft.) 1
7R002-056 #56 Hose clamps 2
7R002-052 #52 Hose clamps 2
8H040-030 Air filter 1
7J250-001 1/4" SAE washers 8
7F250-021 1/4"-20 Nylock nuts 4
7A250-075 1/4"-20 x 3/4" Socket head cap screw 4
7S325-100 3.25 x 1 Sleeve 1
7S350-200 3-1/2 x 2 Sleeve 1
4FA012-012 90
°
Intake elbow 1
7U030-056 3/8" PCV hose (1.250 ft.) 1
7P250-045 1/4 NPT x 3/8 ID fitting 1
7R005-001 208-91 T-bolt clamp 3.75" 1
4FG110-050 MAF bracket assy. 1
7P375-016 3/8 Pipe plug 1
7U100-052 7/16 Rubber grommet 1
4FF101-002 FUEL PUMP ASSEMBLY 1
8F001-002 155 Inline fuel pump 1
8F101-200 T-Rex wiring assy. 1
5W001-010 16-14 Gauge female slide, insulated 3
7R004-003 14.5 Stepless clamps 2
7R001-004 #4 Hose clamps 2
7U030-050 12mm Fuel hose (2.41 ft.) 1
7U031-018 5/16 Fuel hose (2 ft.) 1
7R003-024 Adel clamp, 1-1/2 ID 1
7E010-075 #12 x 3/4" Sheet metal, hex only 2
7P312-003 5/16" Female fuel connector 1
7P500-004 1/2" fuel adapter fitting 1
7C008-032 #8-32 Hex lock nut 1
7J008-001 #8 Flat washer 1
5W001-001 Wire tap 1
7U100-055 Tie wrap, 6" nylon 5
5W001-002 Fuse tap 1
5W001-015 Blade type fuse, 20 amp 1
5W001-014 #10 Fuse holder 1
5W001-019 Solderless connector, 12-10 gauge 1
5W001-011 16-14 Gauge eyelet, .25" bolt 1
7U375-135 Mounting pad 5
7U100-044 Tie wrap 5
7S625-000 Fire sleeve 1 ft.
1994-1998 3.8L V-6 Mustang
Part No. 4FF218-010SQ/018SQ
PARTS LIST
Part Number Description Quantity
4FF111-021 MOUNTING BRACKET ASSEMBLY 1
4FF011-021 Mounting bracket 1
4FF010-034 Mounting plate 1
7C010-066 10mm x 1.5 x 65 bolt 3
7C080-065 8mm x 1.25 x 65 1
7J375-044 3/8" Washer 3
7K312-001 5/16" Washer 1
7A375-100 3/8" - 16 x 1" Screw 5
7A375-075 3/8" - 16 x 3/4" Screw 5
7K375-040 3/8" Flat washer 10
7G010-175 12mm x 1.75 nut 1
2A046-114 Belt 1
4FA016-170 Idler pulley 1
4FD017-011 Idler spacer 1
7C012-050 12mm x 1.75 x 50mm Hex 1
4FA016-171 Dust shield 1
7J012-092 12mm Flat washer 2
2E228-250 V2SQ SUPERCHARGER ASSEMBLY 1
4FF101-003 A/C LINE SUPPLEMENT 1
5W018-020 18 Gauge std. black wire (1.333 ft.) 1
5W018-050 18 Gauge std. yellow wire (1.333 ft.) 1
5W018-070 18 Gauge std. green wire (1.667 ft.) 1
5W018-080 18 Gauge std. blue wire (1.667 ft.) 1
5W001-012 Solderless connector, 22 red gauge 8
5W001-007 3/16" Heat-shrunk tube (1.00 ft.) 1
7P375-039 5/8 x 90
°
Barb 1
7P625-016 5/8 Union 1
7U034-100 5/8 A/C hose (.312 ft.) 1
7R002-010 #10 Clamp 3
4FF112-020 DISCHARGE ASSEMBLY 1
7R002-044 #44 Hose clamps 4
7R002-016 #16 Hose clamps 4
7S275-200 2-3/4” x 2” Sleeve 2
8D001-001 Bypass valve 1
7U034-016 1" Heater hoses (.416 ft.) 1
7U034-016 1" Heater hoses (.229 ft.) 1
4FF012-020 Discharge tube 1
4FF130-026 OIL FEED ASSEMBLY 1
7U030-026 1/4” Oil feed hose (3.16 ft.) 1
7P250-066 #4 Swivel x 1/4” hose barb fitting 4
7P525-067 .525 Crimp ferrules 4
7U100-055 Tie wrap, 6" nylon 2
7P250-144 1/4" NPT x #8 fitting 1
7P250-082 1/4" NPT x #4 90
°
fitting 1
7P125-103 #4 x 45
°
Male elbow 1/8" NPT 1
7P250-034 1/4 NPT Strt., Tee 1
7U030-026 1/4" Oil feed hose (1.58 ft.) 1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any
shortages or damaged parts immediately.
®
