Vortech 1994-2000 Ford 3.8 Mustang User Manual

Page 22

background image

P/N: 4FF020-010
©2003 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
09JUN03 V2.1

(94-00 3.8L Mus.(4FF V2.1))

14

9. EGR TUBE MODIFICATION (1999-2000 VEHICLES EQUIPPED WITH AN EGR TUBE), cont'd.

Fig. 9-c

Fig. 9-b

1/2” NPT - 5/8 TUBE

CONNECTION

EGR TUBE

FLEXIBLE EGR TUBE
