[ 8 ]
CONTROLS & CONNECTIONS
Digital Servo User’s Manual
XLR AUDIO INPUTS
A. LFE InPUT: Balanced XLR inputs.
Connect LFE or left and right balanced
XLR inputs from your receiver or
processor. Either of these inputs can
be used for an LFE signal.
RCA AUDIO INPUTS
B. LFE InPUT: Use one of these two
RCA inputs for the LFE output from
your receiver. Or use the pair for the
left and right channel signals from
your receiver.
SPEAKER LEVEL INPUTS
C. SPEAKER LEVEL: Input for either
banana plug/jack or exposed
wire/terminal connections.
RS-232 INPUT
D. RS-232 In: Communicate with a
computer, a touch panel remote control
or an upstream daisy-chained DS-10
subwoofer.Also, the 12V trigger
feature requires a 12V trigger signal
(+12V or -12V) across pins 7 and
9 of this connector.
RCA AUDIO OUTPUTS
E. THRU: Connect subwoofer output
to downstream subwoofer in a
“daisy-chain.” Output is unfiltered L&R.
F. OUTPUT: Crossed-over high frequency
output signal to send to a preamp. The
preamp amplifies this signal to use as
the audio input to satellite speakers.
g. EQ OUTPUT LEFT/RIgHT: EQ sweep
tone for Auto-EQ and Manual-EQ.
VIDEO OUTPUTS
H. VIDEO OUT: Display the video
generated by the subwoofer on
your TV using composite video.
I. S-VIDEO: Display the video
generated by the subwoofer
on your TV using S-video.
Either connect the VIDEO
OUT or the S-VIDEO
output; not both.
RS-232 OUTPUTS
J. RS323 OUT: Communicate with a
downstream “daisy-chained” DS-10
subwoofer. Also, the 12V trigger
feature requires a 12V trigger signal
(+12V or -12V) across pins 7 and
9 of this connector.
CONTROLS
K. ExTERnAL REMOTE: Allows for
hook-up of the optional Velodyne
remote control receiver. With the
optional receiver plugged in it will
allow the remote control to control
the subwoofer even if the subwoofer
sensor is pointed away from you.
Place the infrared receiver within
direct line of sight from your usual
listening position.
L. MIC: Connect the smaller end of the
mic cable to use the microphone. The
EQ functions will terminate unless the
microphone is connected.
M. Power Receptacle: Connect
detachable AC power plug.
n. POWER: Switch power to the
subwoofer ON and OFF.
O. Serial Tag: Shows serial number,
model number and manufacturing
date for the subwoofer.
