FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
IC Statement:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Quick Start
ResponseCard® NXT
Test Mode
THE TOOLBOX
Find Channels - Automatically detects the receivers within range of
the ResponseCard NXT. Scroll through the rolodex using the left or
right arrow keys to find your channel. Press the Enter button to set the
channel.
Send Message - Send a message to the leader/presenter. The leader
is unable to respond back via the same method. NOTE: The leader/
presenter may have this feature disabled in the software. If this is the
case, you will see a “Not Open” message when trying to send a note.
Device Info - Device Info displays the Device ID.
Contrast - Use the left or right arrows to adjust the contrast of the
objects. Press the Enter button to save.
Your I.D. - Assigns an alphanumeric identification to the ResponseCard.
Brightness - Adjusts the LCD display on the ResponseCard NXT.
Test Info - Displays the test name, version number (if applicable) and
question count. This option is only available while in Test Mode.
Delete Test - Deletes the current test from the ResponseCard. This
option is only available while in Test Mode.
Send Test - Sends the current test to the host computer. This option is
only available while in Test Mode.
CHANGING THE CHANNEL
Before logging into a test, the ResponseCard NXT needs to be on the same
channel as the receiver.
1. Press the Channel button.
2. Use the number pad to enter the new channel number.
3. Once the channel number has been entered,press the Enter button.
LOGGING INTO A TEST
1. Press a button on the ResponseCard to “wake up” the device.
2. The Welcome Screen is displayed followed by the Battery Indicator Screen.
3. You may be prompted for Your ID.
a. Press the left function key to clear the information displayed.
b. Enter Your ID.
c. Press OK.
4. You may be prompted for Test Version.
a. Locate the Test Version number on the paper test.
b. Use the number pad to enter the Test Version.
c. Press OK.
5. The test name, version number (if applicable) and the question count are
displayed.
6. If the information displayed in the previous step is correct, press OK. If the
information is incorrect, press the back button (left function key) , verify that the
ResponseCard is on the correct channel and begin the process from step 1.
You are now in Test Mode.
TAKING A TEST
Single Response - Press the
button that corresponds to the
answer choice. Answer choices
can be alpha or numeric.
5
200. 2. 1. 41 1-10
Go To
ABCDEFGHSDKQMNOP
200. 2. 1.
41 txt ABC
1234567890123456
200. 2. 1.
123... 41
41 txt abc
160
200. 2. 1.
25. 24.
3,1,2...
23. 41
5,3,2,8,1,6,7,10,4,9
C,A,B,E,J,H,G,I,D,F
200. 2. 1.
C,A,B... 41
True
200. 2. 1.
T/F 41
Go To
Short Answer - Enter the text
using the number pad, similar
to cell phone texting. Press
OK once you have made your
Essay - Enter the text using the
number pad, similar to cell phone
texting. Press OK once you have
made your selection.
Numeric Response - Enter the
response using the number pad,
press OK once you have made
your selection.
True or False - Press 1/A for
True or 2/B for False.
Multiple Response - Enter your
answer choices and then press
OK once you have made your
selection. Answer choices can be
alpha or numeric.
NAVIGATING THROUGH QUESTIONS
Scrolling Through Questions
1. Use the left and right arrows to scroll back or
forward through the question rolodex.
Go To a Specific Question
1. Press the left function key.
2. Use the number pad to enter the question
number.
3. Press the Enter button to be taken to the
question.
SENDING A TEST
When answering the last question of the test, you
will receive a message that the test is complete or
incomplete.
Completed Test
1. Press the right function key to send the test.
TIP: Press the left function key to return to the
test and review your answers.
2. The ResponseCard NXT will save the test and
send it to the host computer.
Incomplete Test
1. The ResponseCard NXT displays a list of the
incomplete questions and then prompts you to
send the test.
2. Press the left function key twice to return to the
test.
3. You are automatically taken to the unanswered
questions.
4. Once all the questions have been answered, you
will receive a message that the test is complete.
