PART NUMBERING SYSTEM
S 48 S R 120
01 E R
F
A
Form Factor
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin
Length
Option
Code
S- Small
Power
48V
S- Single
R- Thru-hole 120-12V
01-1.25A E-No ON/OFF
Control
Function
R- 0.170”
N- 0.145”
K- 0.110”
F- RoHS 6/6
(Lead Free)
A- Encapsulated &
Trim
B- Encapsulated &
No Trim
C- Open Frame &
Trim
D- Open Frame &
No Trim
MODEL LIST
MODEL NAME
INPUT
OUTPUT
EFF @ 100% LOAD
S48SR1R805ERFA 36V~75V
0.5A
1.8V
5.0A
80.0%
S48SR2R504ERFA 36V~75V
0.5A 2.5V
4.5A
83.0%
S48SR3R303ERFA 36V~75V
0.5A
3.3V
3.0A
84.5%
S48SR3R304ERFA
36V~75V 0.6A
3.3V 4.5A
86.0%
S48SR05002ERFA 36V~75V
0.5A
5.0V
2.0A
85.0%
S48SR05003ERFA 36V~75V
0.6A
5.0V
3.0A
86.5%
S48SR12001ERFA 36V~75V
0.6A
12.0V 1.25A
86.5%
CONTACT:
www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon request from
Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor
for any infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
