DATASHEET
DS_S48SR12001_07052006

Delta Electronics, Inc.

1

APPLICATIONS

Telecom/DataCom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Test Equipment

OPTIONS

Short pin lengths

FEATURES

High efficiency: 86.5% @ 12V/1.25A

Standard footprint: 2.0” ×1.0”

Industry standard pin out

Low profile

­

Open Frame: 9.1mm (0.36”)

­

Encapsulated: 10.7mm (0.42”)

Fixed frequency operation

Input UVLO, Output OCP, OVP

No minimum load required

2:1 input voltage range

ISO 9001, TL 9000, ISO 14001, QS

9000, OHSAS 18001 certified

manufacturing facility

UL/cUL 60950 (US & Canada)

Recognized, and TUV (EN60950)

Certified

CE mark meets 73/23/EEC and

93/68/EEC directives

Delphi Series S48SR, 15W 2”x1” Family
DC/DC Power Modules: 48 V in, 12V/1.25A out

The Delphi Series S48SR printed circuit board mounted, 48V input,
single output, isolated DC/DC converter is latest offering from a world
leader in power system and technology and manufacturing ― Delta
Electronics, Inc. This product family provides up to 15 watts of power
or up to 4.5A of output current (for 3.3V and below) in an industry
standard footprint. With creative design technology and optimization
of component placement, the Delphi Series Small Power converters
possess outstanding electrical and thermal performance, as well as
extremely high reliability under highly stressful operating conditions.
All models are protected from abnormal input/output voltage and
current conditions. An encapsulated version is available for the most
robust performance in harsh environments.
