9
3. Specifications
IEC 1010 Over Voltage:
CAT II - 1000V
CAT III - 600V
Pollution Degree 2
Temperature for gauranteed accuracy: 23ºC +5ºC
DC VOLTS
Range Res. Accuracy
400mV 0.1mV +/-(0.3% of reading + 5 digits) Impedance:
4V 0.001V 10M Ω
40V 0.01V +/-(0.5% of reading + 4 digits) Overload Protection:
400V 0.1V 600VDC or AC RMS
600V 1V +/-(1.0% of reading + 4 digits)
(40Hz to 60Hz Frequency Response 400mV Range )
AC VOLTS
(40Hz to 400Hz Frequency Response All Other Ranges)
Range Res. Accuracy
400mV 0.1mV +/-(1.5% of reading + 5 digits) Impedance:
4V 0.001V 10M Ω
40V 0.01V +/-(1.5% of reading + 5 digits) Overload Protection:
400V 0.1V 600VDC or AC RMS
600V 1V
8
OHM (
Resistance,
Ω)
Range Res. Accuracy
400 Ω 0.1 Ω
4k Ω 0.001k Ω ±(0.8% of reading +5 digits) Overload Protection:
40k Ω 0.01k Ω
250VDC or AC RMS
400k Ω 0.1kΩ
4M Ω 0.001M Ω ±(2% of reading +10 digits)
40M Ω 0.01M Ω
Frequency (Hz)
Range Res. Accuracy
4000Hz 1Hz
40.00kHz 0.01kHz
400.0kHz 0.1kHz ±(0.5% of reading +2 digits) Overload Protection:
4.000MHz 0.001MHz 250VDC or AC RMS
40.00MHz 0.01MHz
Diode Test
Test Current Over Load Protection
1.5mA MAX 250 V DC or AC RMS
Continuity Buzzer
Test Voltage Threshold Over Load Protection
3V <35 Ω 250 V DC or AC RMS
UL 3111 Pending
(45Hz to 100Hz Frequency Response 200A to 400A)
AC AMPS
(45Hz to 450Hz Frequency Response Below 200A)
Range Res. Accuracy
40A 0.01A +/-(3.0% of reading + 5 digits)
400A 0.1A e
