11 10
Capacitance
Range Res. Accuracy
4nF 0.001nF
40nF 0.01nF
400nF 0.1nF Overload Protection:
4 µF 0.001 µF ±(3% of reading +10 digits) 500VDC or AC RMS
40 µF 0.01 µF
400 µF 0.1uF
4mF 0.001mF ±(7% of reading +10 digits)
nF= nanofarad, µF= microfarad, mF= millifarad
General
Max Voltage between any 600V
input and ground
Fuse Protection ( µµA range) 0.5A/600V
Display Type 4000 Count 41 seg. bargraph
Operating Temperature 32ºF to 113ºF (0ºC to 40ºC)
Storage Temperature -4ºF to 140ºF (-20ºC to 60ºC)
Relative Humidity 80% non-condensing
Power Supply 9V (MN1604)
Battery Life 80 hrs. typical
Size (H x L x W) 32.5mm x 255mm x 65mm
(1.3in x 10in x 2.5in)
Weight 363g (0.8lbs)
Jaws for Measuring
AC Amps Only
RANGE
Push Button
HOLD Push
Button
Rotary
Switch
LCD Display
with Function
Annunciators
Input Jacks
Trigger for
Opening
the Jaws
D. MEASUREMENT TECHNIQUES
1. Controls and Functions:
