Test Products International 265 - Manual (Page 29)

29 28
Accessories
Standard Accessories Part Number
9 Volt Alkaline Battery A009A
Test Lead Set A040
Soft Carrying Pouch A255
Optional Accessories Part Number
Fused Test Lead Kit FTLK3
Deluxe Test Lead Set TLS2000RB
Carbon Monoxide Adapter A771
Pressure Adapter A620
Temperature Adapter A301
Differential Temperature Adapter A312
H. Maintenance
1. Battery Replacement: The 265 will display a battery
symbol when the internal 9 Volt battery needs replace-
ment. The battery is replaced as follows:
a. Disconnect and remove all test leads
from live circuits and from the 265.
b. Loosen the screw from the back of the 265 battery
cover.
c. Remove the battery compartment cover.
d. Remove old battery and replace with new battery.
Observe the correct polarity on the battery.
e. Reassemble the instrument in reverse
order from above.
2. Cleaning your 265:
Use a mild detergent and slightly damp cloth to clean the
surfaces of the 265.
