13 12
Controls and Functions: (cont.)
Input Jacks
COM Black test lead connection for all
measurements except AC Amps.
V/ Ω Ω/ /Hz Red test lead connection for all
measurements except AC Amps.
Controls and Functions: (cont.)
Push Buttons
HOLD Holds the reading on the display
until the button is pushed a
second time.
RANGE Activates manual ranging. Press and
hold for 2 seconds to return to auto
ranging.
Rotary Switch
OFF Turns the 265 completely off.
V Used to measure DC volts.
V Used to measure AC volts.
Ω Ω Used to measure resistance.
Used to measure continuity.
Selects diode test function.
Selects capacitance test function.
Hz Selects frequency test function.
Used to measure AC amperage.
