Test Products International 183A - Manual (Page 6)

11 10
j. Duty Cycle / Hz
Range
0.1 ~99.9% (0.5Hz to 500kHz, Width > 2uS)
Accuracy
((0.1% + 0.05% / kHz) +1 Count
k. Diode Test
Test Voltage Max Test Current Over Load Protection
2.7V Approx. 1mA 600 V DC or Peak AC
l. Continuity Buzzer
Test Voltage Threshold Over Load Protection
0.6V < 30W 600 V DC or Peak AC
m. Capacitance
Range Resolution Accuracy Overload Protection
40nF 0.01nF
400nF 0.1nF
4uF 0.001nF ±(3.0% +10 digits) 600V DC or
40uF 0.01uF AC Peak
400uF 0.1uF
4000uF 1uF ±(7.0% +10 digits)
n. Frequency (Hz)
Range Resolution Accuracy Overload Protection
10Hz 0.01Hz
100Hz 0.1Hz
1KHz 0.001KHz ±(0.05% +3 digits) 600V DC or
10KHz 0.01KHz AC Peak
100KHz 0.1KHz
1MHz 0.001MHz
10MHz 0.01MHz
o. Temperature (K-Type)
Range Resolution Accuracy
CENTIGRADE
-40° to 10°C
0.1° ±(3.0% + 5°C)
10° to 200°C 0.1° ±(1.0% + 3°C)
200° to 400°C 0.1° ±(2.0% + 5°C)
400° to 1300°C 1°C ±(3.0% + 7°C)
FAHRENHEIT
-40° to 50°F
0.1° ±(3.0% + 2.5°F)
50° to 392°F 0.1° ±(1.0% + 1.5°F)
392° to 752°F 0.1° ±(2.0% + 5°C)
752° to 2372°F 1°F ±(2.0% + 5°C)
p. General Specifications
Max. Volt. between 1000V
any Input and Ground
Fuse Protection
mA: 0.5Amp/600VAC A: 10Amp/600VAC
Display Type 4,000 Count, 2 times per second update
Operating Temp. 0° to 40°C (32° to 104°F)
Storage Temp. -10° to 50°C (14° to 122°F)
Relative Humidity 0% to 80%
Power Supply 2 Each 1.5 Volt “AA” Batteries
Battery Life 200 hrs. Typical
Size (H x L x W) 33mm x 86mm x 187mm (1.3in x 3.4in x 7.4in)
Weight 340g (12oz)
