8
3. Specifications
IEC 61010-1 Over Voltage:
CAT II - 1000V
CAT III - 600V
Pollution Degree 2
a. DCmV
Range Resolution Accuracy Impedance
40 mV 0.01mV ±(0.5% + 2 digits) 10MW
400 mV 0.1mV
b. DCV
Range Resolution Accuracy Impedance
400mV 0.1mV
4V 0.001V
40V 0.01V ±(0.5% + 2 digits) 10MW
400V 0.1V
1000V 1V
c. ACmV (True-RMS, 40 - 400Hz)
Range Resolution Accuracy Impedance
40mV 0.01mV ±(1.5% + 3 digits) 10MW
400mV 0.1mV
d. ACV (True-RMS, 40 - 400Hz)
Range Resolution Accuracy Impedance
400mV 0.1mV ±(1.5% + 3 digits)
4V 0.001V
40V 0.01V ±(0.75% + 3 digits) 10MW
400V 0.1V
750V 1V ±(1.0% + 5 digits)
e. ACV (True-RMS, 400Hz - 1kHz)
Range Resolution Accuracy Impedance
4V 0.001V
40V 0.01V ±(1.5% +5 digits) 10MW
400V 0.1V
750V 1V ±(2.0% + 5 digits)
9
*Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating.
f. ACV (True-RMS, 1kHz - 20kHz)
Range Resolution Accuracy Impedance
4V 0.001V
40V 0.01V ±(2.0% + 3 digits) 10MW
400V 0.1V
750V 1V Unspecified
g. DCA
Range Resolution Accuracy Overload Protection
40µA 0.01µA ±(0.8% +2 digits)
400µA 0.1µA Fuse
4000µA 1µA ±(0.8% +5 digits) 0.5Amp/600V
40mA 0.01mA
400mA 0.1mA
4A 0.001A ±(1.2% +5 digits) Fuse
10A 0.01A 10Amp/600V
h. ACA (True-RMS)
Range Resolution Accuracy Overload Protection
400µA 0.1µA Fuse
4000µA 1µA ±(1.2% +5 digits) 0.5Amp/600V
40mA 0.01mA
400mA 0.1mA
4A 0.001A ±(1.5% +10 digits) Fuse
10A 0.01A 10Amp/600V
i. OHM (Resistance, W)
Range Resolution Accuracy Overload Protection
400W 0.1W ±(0.8% +5 digits) 600V DC or
4kW 0.001kW AC Peak
40kW 0.01kW ±(0.5% +3 digits)
400kW 0.1kW
4MW 0.001MW ±(1.0% +5 digits)
40MW 0.01MW ±(1.5% +10 digits)
