h. MEASURING CAPACITANCE
CAUTION!
Disconnect power to the circuit(s) to be
measured. Discharge the capacitorto be
measured completely before attempting to
measure.
Instrument set-up:
FUNCTION BLACK RED MINIMUM MAXIMUM
TEST LEAD TEST LEAD READING READING
CAP COM V WHz 0.01nF 4000uF
Measurement Procedure:
1. Disconnect power and discharge the capacitor to be
measured.
2. Plug the black test lead into the COM input jack.
3. Plug the red test lead into the V WHz input jack.
4. Set the rotary switch to the CAP function.
5. Connect the test leads to the capacitor to be
measured.
6. Read the capacitance on the 183A.
Optional Functions:
REL
HOLD
Activate REL mode (page 24).
Freeze the reading on the LCD.
g. CONTINUITY BUZZER
WARNING!
Do not attempt to make continuity measurements
with circuit energized.
Instrument set-up:
FUNCTION BLACK RED
TEST LEAD
TEST LEAD
COM VWHz
Measurement Procedure:
1. Disconnect power to the circuit to be measured.
2. Plug the black test lead into the COM input jack.
3. Plug the red test lead into the V WHz input jack.
4. Set the rotary switch to the function.
5. Press yellow push button to activate continuity buzzer.
6. Connect the test leads to the circuit to be measured.
7. Listen for the buzzer to confirm continuity.
