SX-20NE-RT-AR User Manual Page 19
VII. Command Line Interface (CLI) Protocol
(continued)
Network Commands
Command Description Admin Fact Def
get network Returns all network settings currently in use. Example:
Mode: DHCP
IP Address: 10.1.2.69
Subnet: 255.255.255.0
Gateway: 10.1.2.1
HTTP Port: 80
Telnet Port: 23
DxP Port: 9100
Timeout: 20
Ok
Yes
set ipmode < static | dhcp > Sets the IP address mode. Static mode locks the IP
address as set; DHCP mode allows a DHCP server to
assign the address. Yes Static
set ipaddress < dotted decimal > Sets the IP address. Yes 192.168.1.254
set subnet < dotted decimal > Sets the Subnet Mask. Yes 255.255.255.0
set gateway < dotted decimal > Sets the Gateway address. Yes 192.168.1.1
set http port < 0-65535 > Sets the port that the internal Web server listens for
incoming connections on. When set to 0 the web server is
disabled. May not be disabled when Telnet and DxP are
both disabled. Yes 80
set telnet port < 0-65535 > Sets the port that the internal Telnet server listens for
incoming connections on. When set to 0 the Telnet server
is disabled. May not be disabled when Web and DxP are
both disabled. Yes 23
set dxp port < 0-65535 > Sets the port that the internal DxP service listens for
incoming connections on. When set to 0 the DxP service
is disabled. May not be disabled when Web and Telnet
are both disabled. Yes 9100
set timeout < 0-999 > Sets the automatic network timeout in minutes. Yes 2
