SA-82-AR / XF2-AR User Manual
Page 6
III. Initial Set-Up
(continued)
Setting the IP Address
ARs are configured with a factory default IP address of 192.168.1.254.
To set the AR’s IP address using one of the following methods, the computer and AR must be
on the same local network.
DMU: Follow the steps in the preceding subsection to set the IP address using the
Device Management Utility (DMU).
CLI: These are the basic commands to set the network parameters. After setting these
parameters, the AR will need to be rebooted for the settings to take effect. Any
command that requires rebooting of the AR will provide a prompt to do so. All commands
may be entered as required before rebooting. Manually specifying the IP address via CLI
automatically sets the address as static.
Example: Telnet to default IP address of 192.168.1.254 on default Port 23:
SurgeX Axess Ready v1.01.41
User> admin
Password> *****
Axess Ready> set ipaddress 10.1.2.69
Ok
Axess Ready Reboot Required> set subnet 255.255.255.0
Ok
Axess Ready Reboot Required> set gateway 10.1.2.1
Ok
Axess Ready Reboot Required> reboot
The CLI command set ipmode dhcp followed by a reboot command may be used to
configure the AR to automatically acquire its network settings from a DHCP server. A
DHCP server will automatically assign an IP address (dynamic address), as well as the
Subnet Mask and Gateway.
To determine what IP address has been automatically assigned by the DHCP server,
you will need to use the Discover feature of the DMU or query your DHCP server and
locate the MAC address of the AR in the DHCP server’s IP/MAC table.
Web: To set the IP address using a web browser, navigate to the current IP address of
the AR (192.168.1.254 if the unit is in a factory default state). Enter the administrator
credentials (Factory Default User: admin, Password: admin), click on “Setup”, then click
on “Network” and follow the directions in the Web Server/Network/Setup section of this
manual.
