SA-82-AR / XF2-AR User Manual
Page 25
X. Specifications
Physical
Height 1.8125”
Width 11.375”
Depth 7.625”
Weight 4.75 lb.
Temperature 5 - 35° C
Humidity Range 5% to 95% R.H., non-condensing
AC
Load Rating 8 Amps @ 120 Volts
Power Requirement (no load) 10 Watts
UL 1449-2 Adjunct Classification
Test Results 1000 surges, 6000 Volts, 3000 Amps,C1 pulse, measured
suppressed voltage 290 Volts, no failures
Maximum Applied Surge Pulse
Joule Rating Unlimited, due to current limiting (8 x 20 µs)
Maximum Applied Surge Pulse
Voltage 6000 volts (1.2 x 50 µs pulse),industry standard rating
Maximum Applied Surge Pulse
Current Unlimited, due to current limiting (8 x 20 µs)*
Endurance IEEE C62.41-1991 Category B3 (C1)
Pulses 1 kV>500,000; 3 kV>10,000; 6 kV>1000
Overvoltage Shutdown 145 Volts (resume at 135 Volts)
EMI/RFI
Filter Normal Mode (50
Ω load) 40 dB@100 kHz; 50 dB@300 kHz;50 dB@3 MHz; 50 dB@30
MHz
Common Mode (50 Ω
load)
18 dB@300 kHz; 30 dB@1 MHz;50 dB@5 MHz; 50 dB@20
MHz
Compliance
UL/cUL UL60950 Listed I.T.E.
File No. E225914
UL 1449 3
rd
Edition In Progress
CE Directives 89/336/EEC, 92/31/EEC and 93/68/EEC
EN 60950: 3
rd
Edition
EN55022: 1998 Class B
FCC Part 15 Class B
Network
Single 10/100 Unshielded Twisted Pair Ethernet Jack
IP Addressed: DHCP Assigned or Static
Internal HTTP Web Server
Forms Processing Browser Required
Internal Telnet Server
*1.2 x 50 µs pulse, industry standard combination wave surge,as per IEEE C62.41
