SA-82-AR / XF2-AR User Manual
Page 2
I. Introduction
The SurgeX
® SA-82-AR/XF2-AR is a network attached, IP addressed, web controlled AC surge
protector and power conditioner. The SA-82-AR/XF2-AR may be used to switch up to 8A at
120V. The simple web server structure allows basic control of two outlets. The extensive
programming and setup capabilities are accessed by a web browser, through a Device
Management Utility (DMU), or through a Command Line Interface (CLI).
• The SA-82-AR/XF2-AR features SurgeX ® Series Mode surge protection, Impedance
Tolerant EMI/RFI filtering and Over-Voltage Shutdown.
• Remote reboot any device: monitors, routers, servers, kiosks, etc. The remote device
need not be network attached.
• Conserve energy by powering down equipment when not in use.
• Telnet access uses the Command Line Interface (CLI) structure and syntax to
completely configure and control the SA-82-AR/XF2-AR. This Axess Ready (AR) device
also supports the DxP protocol, which allows software developers to integrate the unit
into custom applications.
• Up to 2 systems can be continuously monitored with AutoPing, with automatic power
control upon loss of contact. Reboot crashed systems, or provide auto power-up or -
down for environmental controls and notification systems.
• The SA-82-AR/XF2-AR utilizes 2 levels of password security, with only the
administrative account having access to setup and configuration.
Located on the rear panel are the input IEC power plug, network connection (RJ-45), 8A circuit
breaker, and output receptacles.
The front panel contains the Outlet On LED, Self-Test LED, System On LED, and Reset button.
