DE400 User's Guide - Rev. B00 StorCase Technology, Inc.
Installation 11
10. Turn ON power to the computer. If the installation has been successful, and all
cables have been properly attached, the system should boot normally. Although
the computer may not recognize the DE400 yet, the appropriate front panel LED
indicators on the DE400 should illuminate.
11. The new drives may need to be formatted or initialized prior to use with the operating
system and applications software. Refer to the drive and/or computer manu-
facturer's documentation for formatting information.
Figure 6: Receiving Frame Mounting Holes
Mounting Holes
(8 per Side)
