StorCase Technology DE200 Ultra320 - Manual (Page 23)

16 Appendix A - Specifications/Dimensions
StorCase Technology, Inc. Ultra320 DE200 User's Guide - Rev. A01
Environmental Specifications
Operating Storage
Ambient Temperature 0° C to 50° C -45° C to 75° C
Relative Humidity (1) 10% to 80% 10% to 90%
Altitude -1000 to 50,000 ft -1000 to 50,000 ft
-304m to 15240m -304m to 15240m
Shock (2) 10g 60g
(1) Non-condensing with maximum gradient of 10% per hour.
(2) 11 msec pulse width 1/2 sine wave.
Physical
Specifications Carrier Receiving Frame
Height 1.68" (42.7mm) 1.70" (43.2mm)
Width 4.67" (118.6mm) 5.75" (146.1mm)
Depth 7.38" (187.5mm) 8.18" (207.8mm)
Weight 1.2lb (0.55kg) 1.3lb (0.59kg) (1)
Chassis Reliability/Maintainability
MTBF 500,000 Hours
MTTR 5 Minutes
Preventive
Maintenance None
Electrical Specifications
Input +5V 34mA
+12V 660µA
(1))
With carrier removed.
Appendix A - Specifications/Dimensions
SCSI Data Express subsystems conform to the Small Computer Systems Interface (SCSI)
Standard set by the American National Standards Institute (ANSI).
