S20A108 User's Guide - Rev. A02

StorCase Technology, Inc.

Installation

13

WARNING:

Unlocking the carrier unit switches DC power off to the drive.

Since disk drives require a short amount of time to spin down,

allow about 15 seconds before pulling the carrier unit out of the

receiving frame to avoid possible damage to the drive.

3.

Use the alignment tool supplied with the DE200 to select the unit ID number of

the disk drive. Refer to Figure 9 for the location of the Unit ID select switch inside

the receiving frame.

4.

After selecting an appropriate unit ID number, replace the DE200 carrier in the

receiving frame, and LOCK IT IN PLACE.

NOTE:

The lock on the DE200 receiving frame serves two functions: 1) as

a lock to secure the drive, and 2) as a DC power switch for the carrier

unit. The lock must be engaged (turned counterclockwise) in order

to supply power to the drive carrier.

5.

The new drive may need to be formatted or initialized prior to use with the

operating system and applications software. Refer to the drive and/or computer

manufacturer's documentation for formatting information.

Figure 9: Unit ID Select Switch Location

ID Select

Rotating Switch

0179i

Unit ID Number

Display
