Table 1: Option Pin Connector (W1) Signal Descriptions
1 ID0 SCSI ID
2 GND Ground
3 ID1 SCSI ID
4 GND Ground
5 ID2 SCSI ID
6 GND Ground
7 ID3 SCSI ID
8 GND Ground
9 Reserved
10 Reserved
11 SYNC Drive Synchronous Signal
12 GND Ground
13 RMST Remote Start (see Table 2)
14 GND Ground
15 DYST Delay Start (see Table 2)
16 GND Ground
17 Reserved
18 Reserved
19 Reserved
20 Reserved
21 Reserved
22 Reserved
PIN Signal Function
Installing the Receiving Frame
NOTE: For Ultra160 operation, the DE200 requires Ultra160 chassis and cabling.
The drive should be installed into the carrier before installing the receiving frame into the
mounting bay of a computer or expansion chassis.
NOTE: Use a #2 Phillips screwdriver during this procedure.
1. Turn OFF power to the computer.
2. Open the computer system according to the manufacturer’s instructions. If
necessary, temporarily remove any expansion boards that may make installation
difficult.
3. To select the DE200 unit ID remotely through the computer system or external
expansion chassis, the appropriate cable from the system must be connected to
the Option Pin Connector (W1) on the rear of the receiving frame as shown in Table
1 and Figure 7.
