18 Appendix A - Specifications/Dimensions
StorCase Technology, Inc. DE100i-SW160 User's Guide - Rev. C01
Figure A-1: DE100i-SW160 Physical Dimensions
(Dimensions are for reference only)
1.70
(43.2mm)
5.75
(146.1mm)
2.06
(52.3mm)
3.13
(79.5mm)
0.50
(12.7mm)
0.38
(9.7mm)
#6-32 x 8
Receiving
Frame
with Carrier
Carrier
Only
8.18
(207.8mm)
0.25
(6.4mm)
0.15
(3.8mm) 3.13
(79.5mm)
5.50
(139.7mm)
#6-32 x 4
Bottom
1.68
(42.7mm)
4.67
(118.6mm)
7.38
(187.5mm)
0.25
(6.4mm)
0285A
1.75
(44.5mm)
3.75
(95.3mm)
Isolator Board
DE100
Board
Isolator
Board
0.64
(16.3mm)
