Spectrum Controls 1762sc-IF4OF4 User Manual
Page 27

Chapter 3: Configuring the 1762sc-IF4OF4 for RSLogix 500
3-5
User’s Manual Pub. 0300247-01 Rev. C
Output
Range
Output Value Condition
Raw/Prop EU
PID
% FS
-10.00 V dc
Low Range
-29788
-10000
0
-10000
-11.00 V dc
Low Limit
-32768
-11000
-819
-11000
0 to 5V
5.50 V dc
High Limit
32767
5500
18021 11000
5.00 V dc
High Range
26809
5000
16383 10000
0.00 V dc
Low Range
-32768
0
0
0
0.00 V dc
Low Limit
-32768
0
0
0
0 to 10V
11.00 V dc
High Limit
32767
11000 18021 11000
10.00 V dc
High Range
26809
10000 16383 10000
0.00 V dc
Low Range
-32768
0
0
0
0.00 V dc
Low Limit
-32768
0
0
0
1 to 5V
5.50 V dc
High Limit
32767
5500
18431 11250
5.00 V dc
High Range
26809
5000
16383 10000
1.00 V dc
Low Range
-20853
1000
0
0
0.00 V dc
Low Limit
-32768
000
-4096
-2500
3.4.3 Input Channel Configuration (Channels 4 and 5)
Channels 4 and 5 are current only channels. The table below describes the configuration
options for channels 4 and 5.
Table 3-4 (Configuration for Input Channels 4 and 5)
To Select
Make these bit settings
7 6 5 4 3 2 1 0
Filter Frequency
(Ignored if Display
CJC)
17 Hz
0 0
4 Hz
0 1
62 Hz
1 0
470 Hz
1 1
Data Format
Engineering Units X1
0 0
Engineering Units X10
0 1
Raw/Proportional Data
1 0
Scaled for PID
1 1
Input Type
4 to 20 mA
0
0
0 to 20 mA
0 1
Reserved
1 0
Channel Disabled
1 1
Open Circuit
(For Module)
4
Upscale
0
Zero
1
Temperature Scale
(For Module)
4
Deg C
0
Deg
F
1
4
This is a module wide setting which is only recognized within the configuration for Channel 4. The
corresponding bit in Channel 5 is ignored.
