Chapter 4 Operation Section
The dual Synth Trim Control simultaneously adjusts the gain (level) of
the left and right channel inputs. Its normal operating or starting
position is when set fully counterclockwise. In order to help maintain
the extremely high frequency response and low noise characteristics of
the Model SSM, utilize this control only as needed.
If an individual synth or sampler proves too weak, it is good practice to
add level by first pushing up the channel's slide fader if possible, or by
making sure that the synth or sampler plugged into that channel is set to
its maximum output. Should these adjustments fall short, then turn the
Synth Trim Control clockwise until the required mixing level is
obtained. Repeat this procedure each time a new patch, or sample is
chosen.
The equalization section has two independent signal paths and utilize
dual pots that simultaneously adjust the left and right parameters of the
equalizer.
The equalizer for the SSM is a semi-parametric type, whereas the
Frequency Sweep Control adjusts one of the parameters, and the Boost/
Cut Control adjusts the second of the parameters. The third possible
parameter available on a parametric equalizer would be the frequency
bandwidth adjustment. The bandwidth (Q) for the low, mid, and high
bands on the SSM equalizer are fixed at approximately 12db/octave.
This control provides 15db of bell shaped Boost or Cut for the high
frequency range (5K to 15Khz), and is used in conjunction with the
High Frequency Sweep Control (see below). 0db boost/cut (flat) is
obtained when this control is set to its center position.
The High Frequency Sweep Control is used in conjunction with the
High Boost/Cut Control and provides continuous adjustment from 5Khz
(fully counterclockwise) to 15Khz (fully clockwise).
This control provides 15db of bell shaped Boost or Cut in either the low
band (50 to 500hz) or mid band (500hz to 5khz) frequency ranges
dependent on the position of the Low/Mid Band Select Switch (see
below). This control is used in conjunction with the Low/Mid Sweep
Control. 0db boost/cut (flat) is obtained when this control is set to its
center position. 1. Synth Trim Control
3. High Frequency
Sweep Control
2. High Boost/Cut Control
22
Refer to Figure 3 for location of items 1 thru 16.
Equalizer Section
4. Low and Mid
Boost/Cut Control
