Speck Electronics SSM - Manual (Page 13)

Specifications
8
Synthesizer Input Impedence
Patch Point Return Impedence
Effects Return Input Impedence
Cue Return Input Impedence (Unbalanced)
(Transformer Isolated)
Click Return Input Impedence (Unbalanced)
(Transformer Isolated)
Aux Return Input Impedence
Microphone Input Impedence (Optional)
Patch Point Output Impedence
Direct Out Impedence
Effect Send Output Impedence
Program Feed Output Impedence
Monitor Feed Output Impedence
Tuner Feed Output Impedence
Synth Input Level
Patch Point Input Level (High Level Synth)
Effects Return Input Level
Cue Return Input Level
Click Return Input Level
Aux Return Input Level
Microphone Input Level Normal
-20dBu
0dBu
+4dBu
+4dBu
0dBu
+4dBu
-50dBu Maximum
+15dBu
+21dBu
+21dBu
+21dBu
+21dBu
+21dBu
+5dBu
10k Ohms
10k Ohms
10k Ohms
10k Ohms
600 Ohms
10k Ohms
600 Ohms
10k Ohms
150 Ohms
All line outputs are designed to drive
a 600 ohm load and may be operated
into any load 600 ohms or greater.
Direct Output Level
Program Feed Output Level
Monitor Feed Output Level
Effects Send Output Level
Tuner Feed Output Level
Transmitter Feed Output Level
Headphone Output Level Normal
+4 dBu
+4 dBm=0VU
-18dBm=0VU
+4dBu
+4dBu
+4dBu
-10dBu Maximum
+21dbu
+21dBm
+21dBm
+21dBu
+21dBu
+21dBu
+21dBu
4 Watts
Output Distortion(THD+n) Normal
.005%@+4dBm
Maximum
.0072%@+22dBm
Frequency Response
(Synth In to Program Out) 12Hz(-3dB) to 160kHz(-3dB)
18Hz (-.5dB) to 140kHz (-.5dB)
Test Conditions:
-10dBu signal at synth input.
Input slide fader set at #10 position.
Trim control set fully clockwise.
Equalizer In/Out swtich set to Out.
Program master adjusted to indicate 0 VU.
Frequency response measured at program feed-left
with a high quality AC voltmeter.
