Frequency Response
Input Level
Normal
+4 dBu
Maximum
+24dbu
Output Distortion(THD+n)
22Hz to 22KHz @ +24dBu .0014%
Test Conditions:
AP balanced +4dBu signal connected to input.
Gain control set to “0” position.
All Boost/Cut controls set to “0”
Bypass switch set “In”
All other controls and switches “Don’t care”
AP analyzer connected at output
Residual Noise Measurement
Test Conditions:
AP balanced signal connected to input.
AP Generator set “Off”
Gain control set to “0” position.
All Boost/Cut controls set to “0”
Bypass switch set “In”
All other controls and switches “Don’t care”
AP analyzer connected at output
Power requirements (Power Module) 16 VAC, 1.1 Amp
Dimensions HxWxD = 1.75" x 8.5" x 7.25"
(45mm x 216mm x 190mm)
Shipping weight Approximately 5 lbs (2.27Kg)
ALL MEASUREMENTS WERE PERFORMED WITH AN AUDIO PRECISION SYSTEM ONE TEST SET.
Output Level:
(Active Balanced)
(Transformer Balanced)
Normal
+4 dBu
+4 dBu
Maximum
+28dbu
+24dBu
Input Impedance 20K Ohms
Output Impedance
(Active Balanced)
(Transformer Balanced)
120 Ohms
600 Ohms
Measured at active balanced output
Measured at transformer output
5Hz(-0.5dB) to 103kHz(-0.5dB)
2Hz(-3dB) to 154kHz(-3dB)
10Hz(-0.5dB) to 110kHz(-0.5dB)
10Hz(-3dB) to 154kHz(-3dB)
Residual Noise Measurement
(22Hz-22kHz)
(10Hz-80kHz)
-93 dBu
-87 dBu
4 Chapter 1 Introduction Section
Specifications
