Simaudio Neo 340i Integrated Amplifier - Manual (Page 15)

340i Integrated Amplifier
____________________________________________________________________________________
15
Remote Control Operation
The Nēo 340i Integrated Amplifier uses the ‘CRM-2’ full-function remote
control (figure 7). It operates on the Philips RC-5 communication protocol
and is can be used with other Simaudio MOON components.
The ‘CRM-2’ remote uses two AA batteries (included). To install them,
simply slide the back plate off in the direction of the arrow; insert the
batteries in the correct direction and then replace the back plate.
To engage the ‘CRM-2’ remote for use with the Nēo 340i Integrated
Amplifier, you must first press the button labeled AMP.
The POWER button located on the upper left will switch the integrated
amplifier to either ‘Standby’ or ‘On’ mode.
The DISPLAY button turns the front panel display on and off
The 2 buttons labelled ◄ INPUT ► allow you to sequentially scroll, either
backwards or forwards, through all six (6) available inputs. For example, to
switch from the “CD” to the “VIDEO” input you may press either ◄ INPUT
three (3) times or INPUT ► three (3) times. Pressing and holding
down either of these buttons results in only a single change to the
selected input.
The 2 buttons labelled ▼ VOL ▲ allow you to control the volume level.
Pressing ▼ VOL results in a decrease in the volume level; Pressing VOL ▲
results in an increase in the volume level. You may either press and hold
these buttons down or press them briefly to make volume adjustments.
The MUTE button turns off the output volume. Pressing the “Mute” button a
second time will reinstate the output volume level back to its current setting.
NOTE: The buttons labelled ◄ BAL ► don’t affect the operation of the 340i.
Figure 5: CRM-2
Remote Control
