Rta-s07 p.5 – RTA Products RTA-S07 User Manual
Page 5
Cam lock
Cam bolt
1.
2.
3.
Screw the bolt into the
corresponding panel.
In the other panel, insert
and align the cam lock.
Join the panels.
Turn the cam lock.
MISALIGNED:
TURN CAM LOCK
TO POINT TOWARDS
THE HOLE
CORRECT
HOW TO ASSEMBLE USING BOLTS AND CAM LOCKS:
If the panel already comes with the cam lock inserted, make sure is aligned:
RTA-S07
P.5
