P.13 RTA-S07
7
8
18
5
Slide the Drawer Bottom Panel (5) thru the channels in between
panels (7), (8) and (9) as shown. Make sure the panel fits inside
all the channels.
7
8
10
9
11
10
SCREWS
4PCS
4X35 MM B
19
20
Assemble the File Drawer Back Panel (10) to the File Drawer Left
& Right Panels (7&8) using Screws (B) as shown.
Carefully insert the File Tubes (11) thru the File Drawer Back Panel (10)
and screw them into the insert of the File Drawer Front Panel (9).
WARNING: DO NOT OVERTIGHTEN the tubes as it may perforate and
damage the front panel. Such damage is not covered by the product's
warranty.
